31.5-inch UHD/4K professional multi-format LCD monitor with superior black level and 2000:1 contrast for post production
Product Description
The HDQLINE Q family represents our latest generation of multi-standard Broadcast 4K/UHD Monitors, using the most precise LCD panel technology available today. Heart of the HDQLINE platform is an advanced high-precision video processing engine supporting resolutions up to 4096x2160 pixels, controlled by a fast embedded processor and cleverly designed software.
Product Highlights
*Remark: The monitor does not support the color space in full.Technical Specifications
Model QDP 320 HC-A
Panel α-Si TFT active Matrix LCD, LED backlight
Screen Size 31.5" wide format
Aspect Ratio 16:9
Native Resolution 3840x2160 Pixels
Effective Screen Size 697.30mm (H) x 392.23 mm (V)
Colors Approx. 1.06 billion
Brightness 100 cd/m² (conform to EBU) or user selectable / max. 400 cd/m²
Contrast Ratio 2000:1
Panel Frame Rate 48 Hz / 50 Hz / 60 Hz (48 Hz and 60 Hz are also compatible with 1/1.001 frame rates)
Response Time 14ms (grey to grey)
Viewing Angle H 178°/V 178°
Color Space ITU-R BT.709, ITU-R BT.601, DCI-P3*, ITU-R BT.2020*
* The monitor does not support the color space in full
Color Temperature D65, user selectable by DCS+ software
EOTF SDR Gamma (1.8-2.6 in 0.05 steps), SDR Bt.1886, HLG, PQ, Slog-3
Scaling Native / 4:3 / 16:9 / full screen / UMD / Quad/ Side By Side / Split View / Measure View**
Deinterlacer High performance motion adaptive deinterlacer
SDI Input 2x BNC (3G/HD/SD-SDI), Input impedance: 75 Ω unbalanced
HDMI Input 1x HDMI 1.4a (HDCP 1.4) up to 1920x1200, 1x HDMI 2.0b up to 4096x2160
DP Input Display Port 1.1 (HDCP 1.4) up to 1920x1200
SFP Input 2x SFP+ Cages for dual SDI (3G/HD/SD-SDI) receiver copper/fiber modules
SDI Output Loop Out (3G/HD/SD-SDI), Output impedance: 75 Ω unbalanced
Headphone Output Stereo 3.5mm mini jack
Ethernet LAN Ethernet, 10BASE-T/100BASE-TX/1000BASE-T RJ-45
AUX External keyboard, light control RJ-10 (4 pin)
GPIO RJ-45 (8 pin)
USB USB 2.0 connector
Option Slot Supports one optional I/O module* (e.g. QIO Dual 12G SDI or QIO Video over IP ST2110)
* No option slot available for low profile monitor variants
Operating Temperature 5 °C - 35 °C
Power Requirement AC 100 - 240V, 50/60 Hz
Power consumption min (± 5% tolerance) 45 W
Power consumption typ (± 5% tolerance) 50 W
Power consumption max (± 5% tolerance) 90 W
Dimensions (Width x Height x Depth) 723 mm x 425 mm x 87 mm
Weight excluding Mounting (± 3% tolerance) approx 9.8 kg
Mounting VESA MIS-D, 100 x 100, M4 x 10 mm, C
Color RAL 9005 black
